The Clevertronics L10 Ultrablade Pro Recessed Exit is a sophisticated emergency exit luminaire designed for recessed ceiling mounting. This product provides a clear and compliant exit indication with its special invisible graphic blade (Running Man).

Features:

• L10 Optimum Ultrablade Pro Recessed Exit with Special Invisible Graphic Blade and with Low Intensity Charge LED, Enabled with Clevertest Plus
• PC/ABS body with PC diffuser
• Recessed Ceiling Mounting
• Dimensions: 317mm x 8.7mm x 157mm
• Ceiling Hole Cut-Out: 350mm x 48mm
  Minimum Ceiling Depth: 80mm
• Weight: 1.1kg
• Non-maintained Operating Mode
• Battery: Lithium Nanophosphate, 3.3V 2500mAh
• Charging Method: Intelligent current-limited constant voltage
• Diffuser: Special Invisible Graphic Blade (Running Man)
• Lamp(s): 12 x 1 Duris E3 LED, 100,000 hours
• Operating Voltage: 240V AC; 50Hz
• Power Consumption: 1.1 Watts (Standby), 3.4 Watts (Max)
• IP Rating: IP20
• Operating Temperature: 1°C to 40°C
• AS2293 Classification: N/A
• Viewing Distance: 24m
• Applicable Standards: AS/NZS3820, CISPR15, AS/NZS2293.3 (with the exception of the EXIT decal)
• Compliance Marking (RCM)

Ensure the safety and compliance of your building with the Clevertronics L10 Ultrablade Pro Recessed Exit. Contact us today for more information or to place an order.

Positioning:

The Clevertronics L10 Ultrablade Pro Recessed Exit can be installed in various locations within buildings, including:

• Commercial offices: Provide clear exit guidance in workspaces.
• Retail environments: Ensure customer safety during emergencies.
• Public facilities: Guide occupants to safety in high-traffic areas.

By strategically placing these exit luminaires, you can enhance the safety and evacuation procedures of your premises.

Specifications:

• | Description | L10 Optimum Ultrablade Pro Recessed Exit with Special Invisible Graphic Blade and with Low Intensity Charge LED |
• | Dimensions (mm) | 317 x 8.7 x 157 |
• | Ceiling Hole Cut-Out (mm) | 350 x 48 |
• | Viewing Distance (m) | 24 |

For more information on emergency lighting standards and regulations, refer to relevant Australian Standards and building codes.
